Victron Phoenix 375VA - 48V with VE Direct

Phoenix inverter 24V 375VA (top)Click to enlarge product image
Phoenix inverter 24V 375VA (top)
  • £123.97 inc. VAT

  • 08006VT72
  • 5 in stock
  • No reviews yet
  • More Details

  Name Code Power (W)   Dim. (L x W mm) Price UK Del.
  Victron Phoenix 250VA - 12V with VE Direct 08006VT01 200.00 260 x 165 £84.66 £6.25 Buy Now
  Victron Phoenix 250VA - 24V with VE Direct 08006VT69 200.00 260 x 165 £84.66 £6.25 Buy Now
  Victron Phoenix 250VA - 48V with VE Direct 08006VT70 200.00 260 x 165 £98.78 £6.25 Buy Now
  Victron Phoenix 375VA - 12V with VE Direct 08006VT02 300.00 260 x 165 £109.86 £6.25 Buy Now
  Victron Phoenix 375VA - 24V with VE Direct 08006VT71 300.00 260 x 165 £109.86 £6.25 Buy Now
  Victron Phoenix 375VA - 48V with VE Direct 08006VT72 300.00 260 x 165 £123.97 £6.25 Buy Now
  Victron Phoenix 500VA - 12V with VE Direct 08006VT03 400.00 275 x 172 £159.25 £6.25 Buy Now
  Victron Phoenix 500VA - 24V with VE Direct 08006VT73 400.00 275 x 172 £159.25 £6.25 Buy Now
  Victron Phoenix 500VA - 48V with VE Direct 08006VT74 400.00 275 x 172 £178.40 £6.25 Buy Now
  Victron Phoenix 800VA - 12V with VE Direct 08006VT04 650.00 325 x 230 £246.95 £15.00 Buy Now
  Victron Phoenix 800VA - 24V with VE Direct 08006VT75 650.00 305 x 216 £246.95 £15.00 Buy Now
  Victron Phoenix 800VA - 48V with VE Direct 08006VT76 650.00 305 x 216 £265.09 £15.00 Buy Now
  Victron Phoenix 1200VA - 12V with VE Direct 08006VT25 1000.00 362 x 232 £361.86 £15.00 Buy Now
  Victron Phoenix 1200VA - 24V with VE Direct 08006VT77 1000.00 327 x 232 £361.86 £15.00 Buy Now
  Victron Phoenix 1200VA - 48V with VE Direct 08006VT78 1000.00 327 x 232 £388.07 £15.00 Buy Now

Victron Pheonix inverters for converting battery voltage (12V, 24V, 48V DC) to mains voltage (240V AC) to run appliances.

Now with a VE.Direct port these inveters can be connected to:

  • A computer (VE.Direct to USB interface cable needed)
  • Apple and Android smartphones, tablets, macbooks and other devices (VE.Direct Bluetooth Smart dongle needed)

Configurable options:

  • Low voltage alarm trip and reset levels
  • Low voltage cut-off and restart levels
  • Output voltage 210 - 245V
  • Frequency 50Hz or 60Hz
  • ECO mode on/off and ECO mode sense level

 Monitoring:

  • In and output voltage and current alarms

Main Features

  • Short circuit proof and protection against overheating from overload or ambient temperature
  • ECO Mode, when in ECO mode the inverter will switch into standby mode when the load is below a minimum load of 15 watts. Once in standy mode the inverter will switch on every few seconds to search for a load above 15 watts, if a load is found then the inverter will stay switched on until the load is switched off
  • Remote on/off, a remote switch can be connected to a two pole connector or betwwen the battery plus and the left hand contact of the 2 pole connector
  • The inverter can be diagnosed for problems with the LEDs, please see manual for more information
  • The standard output socket is a UK socket, however there are other sockets available: Schuko, AU/NZ, IEC-320 and Nema 5-15R
  • 5 years warranty
  • *
  • *
  • *
  • *
