GivEnergy 5.0kW Hybrid Kit

GIV-HY-5.0-G3
GIV-HY-5.0-G3

  • £9258.48 inc. VAT

  • 05002GE05
  • 5 in stock
  • No reviews yet

  • More Details

  Name Code Power (W)   Dim. (L x W mm) Price UK Del.
  GivEnergy 3.6kW Hybrid Kit 05002GE04 3680.00 1722 x 1134 £6654.19 £99.00 Buy Now
  GivEnergy 5.0kW Hybrid Kit 05002GE05 5000.00 1722 x 1134 £9258.48 £99.00 Buy Now

Kit Contents:

Please phone if you require further information regarding the kit list or would like something changed for your order.

  • 12 x JA Solar 415W Mono PERC Half-Cell MBB Black Frame Panels
  • 1 x Renusol Pantile Roof Rail Mounting System
  • 2 x MC4 Connector Twin Pack
  • 2 x 4mm2 single-core DC cable 50m - Black
  • 1 x IMO Stag AC Isolator 3 Pole 32 Amp
  • 1 x Enclosed DC Switch IP66 4 pole 2 string 16A 800V
  • 1 x Emlite 1-ph Bi-Directional generation meter 100A (1000 pulse/kWh) incl. Cover
  • 1 x PV on Roof and Hazard Labels Pack
  • 1 x GivEnergy 1PH Hybrid Inverter 5.0kW 3rd Generation
  • 1 x GivEnergy Single Phase Energy Meter with CT
  • 2 x GivEnergy Battery Isolator 100A DC MCB
  • 1 x Battery Isolator Metal Clad Enclosure
  • 1 x GivEnergy Battery cable for Gen 2 to Gen 2
  • 1 x GivEnergy Grommet for cable
  • 1 x GivEnergy 9.5kWh Li-Ion Battery - Gen 2
  • 1 x GivEnergy PE Bonding Kit for Gen3 Hybrid Inverters
  • 1 x Battery Hazard Label Pack

Note:

  • You must be an approved GivEnergy installer to install and commission this system
  • Panels may vary according to stock levels, but will be as close to 5.0kW as possible
  • The above mounting system is based on a pantile roof. An alternative mounting system may be required for slate or flat roofs
  • 3.68kW is currently the maximum sized system that can be installed by an MCS installer on a self certification basis. If a larger system is required, permission is needed by the DNO before installation
  • *
  • *
  • *
  • *
