Solis 3.6kW Hybrid Kit
JAM54S-30-415-MR-BF
Name | Code | Power (W) | Dim. (L x W mm) | Price | UK Del. | ||
---|---|---|---|---|---|---|---|
Solis 3.6kW Hybrid Kit | 05002SO02 | 3600.00 | 1722 x 1134 | £5732.87 | £99.00 | Buy Now | |
Solis 5.0kW Hybrid Kit | 05002SO03 | 5000.00 | 1722 x 1134 | £8220.14 | £99.00 | Buy Now |
Kit Contents:
Please phone if you require further information regarding the kit list or would like something changed for your order.
- 9 x JA Solar 415W Mono PERC Half-Cell MBB Black Frame Panels
- 1 x Renusol Pantile Roof Rail Mounting System
- 2 x MC4 Connector Twin Pack
- 2 x 4mm2 single-core DC cable 50m - Black
- 1 x IMO Stag AC Isolator 3 Pole 20 Amp
- 1 x Enclosed DC Switch IP66 4 pole 2 string 16A 800V
- 1 x Emlite 1-ph Bi-Directional generation meter 100A (1000 pulse/kWh) incl. Cover
- 1 x PV on Roof and Hazard Labels Pack
- 1 x EH1 Solis Energy Storage 3.6kW Hybrid 5G Inverter with DC switch
- 1 x Solis Data Logging Stick - WiFi Gen 3 - S3-WIFI-ST
- 1 x KETO Battery Disconnector with 100A Fuses
- 1 x Battery Isolator Metal Clad Enclosure
- 1 x 2m Cable pack for US5000 battery models
- 1 x Pylon US5000 4.8kWh Li-Ion Solar Battery 48V (excl. brackets)
- 1 x 2xBrackets - Pylon US5000
- 1 x Battery Hazard Label Pack
Note:
- Panels may vary according to stock levels, but will be as close to 3.68kW as possible
- The above mounting system is based on a pantile roof. An alternative mounting system may be required for slate or flat roofs
- 3.68kW is currently the maximum sized system that can be installed by an MCS installer on a self certification basis. If a larger system is required, permission is needed by the DNO before installation
Related Documents
- ECA2nz installer notes
- Limited Warranty for JA Solar Brand Crystalline Solar PV Modules 2020.9
- JA Solar Single-glass modules standard installation manual A15 20210524
- JAM54S30 390-415 MR BF EN 15-25 Superior Warranty
- PM0MUS500255-US5000 US5000-B-SD21US501001-Installation manual
- US5000 spec (1)
- Solis Inverter Warranty - UK
- SOLIS-G99GB
- Solis Leaflet Battery matching RHI-(3-6)K-48ES-5G V34 2023 09
- Solis Manual S5 EH1P(3-6)K-L EUR V1.2 (3)
- Datasheet S5-EH1P(3-6)K-L GBR V2.1 2022 10
