Solis 5.0kW Hybrid Kit

JAM54S-30-415-MR-BF
JAM54S-30-415-MR-BF

  • £8220.14 inc. VAT

  • 05002SO03
  • 5 in stock
  • No reviews yet

  • More Details

  Name Code Power (W)   Dim. (L x W mm) Price UK Del.
  Solis 3.6kW Hybrid Kit 05002SO02 3600.00 1722 x 1134 £5732.87 £99.00 Buy Now
  Solis 5.0kW Hybrid Kit 05002SO03 5000.00 1722 x 1134 £8220.14 £99.00 Buy Now

Kit Contents:

Please phone if you require further information regarding the kit list or would like something changed for your order.

  • 12 x JA Solar 415W Mono PERC Half-Cell MBB Black Frame Panels
  • 1 x Renusol Pantile Roof Rail Mounting System
  • 2 x MC4 Connector Twin Pack
  • 2 x 4mm2 single-core DC cable 50m - Black
  • 1 x K&N Single Phase AC Switch Disconnector 32A
  • 1 x Enclosed DC Switch IP66 4 pole 2 string 16A 800V
  • 1 x Emlite 1-ph Bi-Directional generation meter 100A (1000 pulse/kWh) incl. Cover
  • 1 x PV on Roof and Hazard Labels Pack
  • 1 x EH1 Solis Energy Storage 5kW Hybrid 5G Inverter with DC switch
  • 1 x Solis Data Logging Stick - WiFi Gen 3 - S3-WIFI-ST
  • 1 x KETO Battery Disconnector with 125A Fuses
  • 1 x 2m Cable pack for US5000 battery models
  • 2 x Pylon US5000 4.8kWh Li-Ion Solar Battery 48V (excl. brackets)
  • 4 x Brackets - Pylon US5000
  • 1 x Battery Hazard Label Pack

Note:

  • Panels may vary according to stock levels, but will be as close to 3.68kW as possible
  • The above mounting system is based on a pantile roof. An alternative mounting system may be required for slate or flat roofs
  • 3.68kW is currently the maximum sized system that can be installed by an MCS installer on a self certification basis. If a larger system is required, permission is needed by the DNO before installation
  • *
  • *
  • *
  • *
